Displacement Pumps
With our diverse standard and high performance pumps we are able to serve all your needs and respond to any challenge. Our Rotierende Verdrängerpumpen are robust, self-priming and have running dry running capability.
- Pressures up to 120 bar
- Flowrates from 1,5 l/h to 300m3/h
- Viscosity up to 1.400.000 mPas
- Temperature up to 450°C
- Efficiency up to 92%
- Suction lift up to 8m
- Solids up to 90%
APPLICATIONS
Chemical Industry
To meet the needs of the chemical industry we offer in addition to our conventional pump range, special and custom pumps built out of special materials with high performance coating, heating and cooling jacket.
Oil, Gas & Petrochemical Industry
We offer self-priming rotary lobe pumps with heating or cooling jacket and seals such as ATEX, “TA-Luft” or API compliant to deliver crude oil and all types of bitumen including those containing solids.
Paint & Varnish Industry
Manufacturers of paints and coatings use a wide variety of pumping tasks in production. Positive displacement pumps meter, convey, mix, empty and fill.
Recycling Industry
Together with system suppliers and end customers, ZEILFELDER Pumpen develops application-specific pump technology that meets the respective requirements. The focus here is on process stability and sustainability.
Plastics Industry
Liquid polymers and polymer solutions, as well as polymer melts, require robust and consistent pump technology that delivers reliable results.
Pharmaceutical & Cosmetic Industry
To respond to the requirements of the pharmaceutical industry we have designed pumps with reduced surface roughness down to 4μ, CIP (cleaning in place) cleaning connections and aseptic connections.
Construction Industry
Our pumps deliver primary materials, protective agents, white cement, glue, silicone, waste water and filled bitumen for the building industry. We offer pumps for high temperature applications with heating jackets.
Animal Feed Industry
Our stainless steel CIP rotary lobe pump range is FDA compliant and particulary suitable for the meet and animal feed industry.
Food Industry
Our stainless steel CIP rotary lobe pump range is FDA compliant and particulary suitable for the food industry.
PRODUCTS
GEAR PUMPS
High performance gear pumps
With our diverse standard and high performance gear pump range we are able to serve all your needs and respond to any challenge. Our gear pumps are robust, self-priming and are designed for your specific application.
On demand, we can provide external gear pumps which are API, ATEX,TR-CU 10, TR-CU 12 and TA Luft compliant
Pressure: up to 120 bar
Viscosity: up to 150,000 mPas
Flow rates: up to 5000 l/min (300 m³/h)
Suction lift: up to 6 m
Temperature: -60 to 450°C
INTERNAL GEAR PUMPS
Standard gear pumps
With our standard internal gear pumps we offer a cost effective alternative solution to cover standard applications.
On demand, we can provide external gear pumps which are API, ATEX,TR-CU 10, TR-CU 12 and TA Luft compliant
Pressure: up to 14 bar
Viscosity: up to 55,000 mPas
Flow rates: up to 4120 l/min (250 m³/h)
Suction lift: up to 4 m
Temperature: -40 to 300°C
ROTARY LOBE PUMPS
For all high viscosity liquids with or without solids
With our diverse standard and high performance pumps we are able to serve all your needs and response to any challenge.
Our Rotierende Verdrängerpumpen are robust, self-priming and have running dry capability.
On demand, we provide as well pumps which are API, ATEX,TR-CU 10, TR-CU 12 and TA Luft compliant.
Pressure: up to 64 bar
Viscosity: up to 3,400,000 mPas
Flow rates: up to 5000 l/min (300 m³/h)
Suction lift: up to 8 m
Temperature: -60 to 450°C
MODULAR PUMP DESIGN
PUMP CONFIGURATOR
New: The Online
Pump Configurator
Fast and Easy Pump Setup
Allows you to properly configure, calculate and select a Zeilfelder Pump.
Combine the used liquid, its viscosity, the requested working pressure, temperature etc… and the configurator will choose the right pump to cover your needs.
